Electrical Safety Matting

Located in Houston, Texas, Mats, Inc. is a major supplier of dielectric, switchboard matting. Mats, Inc. stocks a variety of electrical matting in different thicknesses, with different surfaces & specifications. Electrical suppliers appreciate our easy access, wholesale pricing and stock on hand. Listed below are some of our most popular dielectric, switchboard materials.


Electrical / Switchboard Matting

Mats, Inc. is a major distributor of dielectric, insulating, switchboard matting. This type of matting must meet certain voltage standards to conform to OSHA & ASTM regulations for use near electrical machinery such as fuse boxes, control panels and other heavy electrical equipment used in settings such as oilfields & on offshore rigs. All electrical, switchboard matting that meets the required specifications has a stamp on the back statingASTMType and Class, as well as the name of the Manufacturer. Mats, Inc. can supply a Certificate of Conformance with any purchase of our electrical, switchboard matting. Review the voltage & mil spec specifications on the products below to decide which material fits your needs.


Rubber & Vinyl Runners

Mats, Inc. offers a variety of rubber & vinyl runners. These materials are used as aisle & hallway coverings to protect floors. Our smooth runner matting is often used to cover work tables. Mats, Inc. provides an assortment of materials in different thicknesses and surface patterns. Some matting is formulated to be especially resistant to grease, oils & chemicals and work well in oily environments. These materials are used in areas where the need for electrical voltage is not a factor. Listed below are the runners purchased most often.

per page
Set Descending Direction
  1. CORRUGATED RUBBER MATTING

    Corrugated Rubber Matting (#0201)

    Starting at: $0.00

    • Runner matting for heavy traffic areas, where non-slip, high traction features are required.
    • Quiets noise, saves floors in wet or dry weather.
    • Most widely used where floor protection and safety are vitally important.
    • Easy to clean, won't curl.
    • This matting can be handled more easily under cold conditions than can vinyl.

  2. Smooth Vinyl Matting

    Smooth Vinyl Matting (#0202)

    Starting at: $0.00

    • This vinyl matting is smooth on both sides.
    • Great for protecting counter tops, work benches and tool boxes.
    • This material is oil and water resistant and is not affected by most corrosive chemicals.

  3. Wide Rib Vinyl

    Wide Rib Vinyl Matting (#0203)

    Starting at: $0.00

    • Same popular design as our standard corrugated rubber matting, but at a very economical price.
    • Quiets noise, saves floors in wet or dry weather.
    • Most widely used where floor protection and safety are vitally important.
    • Easy to clean.

  4. Corrugated Vinyl Matting

    Corrugated Vinyl Matting (#0203A)

    Starting at: $0.00

    • Same popular design as our standard corrugated rubber matting, but at a very economical price.
    • Quiets noise, saves floors in wet or dry weather.
    • Most widely used where floor protection and safety are vitally important.
    • Easy to clean.

  5. Diamond Plate Vinyl Matting

    Diamond Plate Vinyl Matting (#0205)

    Starting at: $0.00

    • Diamond plate is a uniquely engineered, deeply- embossed, steel design matting.
    • It is recommended for heavy traffic areas where floor protection and safety are important.
    • It exhibits exceptional wear characteristics and is ideal for heavy traffic.
    • Also has good resistance to most beverages, normal oils, usual household cleaners and common industrial chemicals.

  6. Heavy Duty Corrugated Vinyl Matting

    Heavy Duty Corrugated Vinyl Matting (#0208A)

    Starting at: $0.00

    • This double thick matting combines toughness for long wear in heavy traffic areas.
    • Resistant to oils, greases, and chemicals.
    • Sharp, v-rib corrugations run lengthwise on this matting and are designed to help remove dirt and protect floors.

  7. Knob Top Niru Rubber Matting

    Knob Top Niru Rubber Matting (#0211B)

    Starting at: $0.00

    • The tough knobbed bar design of this matting adds safety and traction in all wet and dry applications.
    • The rubber is compounded of 100% nitrile for grease resistance.
    • This matting is ideal for food processing plants, kitchens, hospitals, laboratories and industrial plants.

  8. Versa Runner Rubber Matting

    Versa Runner Rubber Matting (#0211CHD)

    Starting at: $0.00

    • This thick, heavy duty mat has done excellent work in kitchens, food processing plants, locker/shower rooms, around swimming pools and behind bars.
    • It is compounded to resist grease, oil, acids, and alkalies.
    • Slotted holes provide good drainage.
    • This matting gives greater foot-ease and stability.

  9. Corrugated Rubber Switchboard Matting

    Corrugated Rubber Switchboard Matting (ASTM) (#0213)

    Starting at: $0.00

    • Conforms to ANSI/ASTM D178-93, TYPE I, CLASS 2.
    • Proof tested at 20,000 volts A.C.
    • Maximum recommended use voltage is 17,000 volts.
    • Dielectric strength - 30,000 volts A.C.
    • Conforms to OSHA regulations for use near electrical machinery such as fuse boxes, control panels and other heavy electrical equipment.

  10. Diamond Plate Vinyl Swithcboard Matting

    Diamond Plate Vinyl Switchboard Matting (Mil Spec) (#0213D)

    Starting at: $0.00

    • Conforms to MIL-DTL-15562G (formally MIL-M- 15562F), Type III.
    • Dielectric Test Voltage -30,000 VAC.
    • Proof Tested Over Entire Surface at -15,000 VAC.
    • Recommended Maximum Use Voltage -3,000 VAC.
    • This matting uses the functional diamond deck plate pattern for a non slip surface.
    • There are many industrial applications for a matting of this quality.

  11. Smooth Marbleized Vinyl Switchboard Matting

    Smooth Marbleized Vinyl Switchboard Matting (Mil Spec) (#0213M)

    $0.00
    • A smooth surface, high voltage insulating vinyl floor covering designed to protect personnel from accidental exposure to electrical potentials not exceeding 3000 volts.
    • Conforms to MIL-DTL-15562G (FORMALLY MIL-M-15562F), TYPE I.
    • Dielectric Test Voltage -30,000 VAC.
    • Proof Tested Over Entire Surface at -15,000 VAC.
    • Recommended Maximum Use Voltage -3,000 VAC.
    • Marbelized colors.

  12. Smooth Vinyl Switchboard Matting

    Smooth Vinyl Switchboard Matting (Mil Spec) (#0213S)

    Starting at: $0.00

    • A smooth surface, high voltage insulating vinyl floor covering designed to protect personnel from accidental exposure to electrical potentials not exceeding 3000 volts.
    • Conforms to MIL-DTL-15562G (FORMALLY MIL-M-15562F), TYPE II.
    • Dielectric Test Voltage -30,000 VAC.
    • Proof Tested Over Entire Surface at -15,000 VAC.
    • Recommended Maximum Use Voltage -3,000 VAC.

  13. Corrugated Vinyl Switchboard Matting

    Corrugated Vinyl Switchboard Matting (ASTM) (#0213V)

    Starting at: $0.00

    • Conforms to ANSI/ASTM D178, TYPE II, CLASS 2.
    • Conforms to TABLE 3 for oil-resistance and flame-resistance.
    • Dielectric strength 30,000 volts A.C.
    • Proof tested at 20,000 volts A.C.
    • Recommended maximum use voltage is 17,000 A.C.
    • Corrugated pattern.

  14. Diamond Plate Vinyl Switchboard Matting

    Diamond Plate Vinyl Switchboard Matting (ASTM) (#0213VD)

    Starting at: $0.00

    • Conforms to ANSI/ASTM D178, TYPE II, CLASS 2.
    • Conforms to TABLE 3 for oil-resistance and flame-resistance.
    • Dielectric strength 30,000 volts A.C.
    • Proof tested at 20,000 volts A.C.
    • Recommended maximum use voltage is 17,000 A.C.
    • Diamond pattern.

  15. Diamond Plate Vinyl Switchboard Matting

    Diamond Plate Vinyl Switchboard Matting (ASTM) (#0213VDY)

    Starting at: $0.00

    • Conforms to ANSI/ASTM D178, TYPE II, CLASS 2.
    • Conforms to TABLE 3 for oil-resistance and flame-resistance.
    • Dielectric strength 30,000 volts A.C.
    • Proof tested at 20,000 volts A.C.
    • Recommended maximum use voltage is 17,000 A.C.
    • Diamond pattern.
    • Black with Yellow Safety border.
    • Clearly marked with supplier name, ASTM D178, Type II, Class 2 on the back.

  16. Corrugated Vinyl Switchboard Matting

    Corrugated Vinyl Switchboard Matting (ASTM) (#0213VY)

    Starting at: $0.00

    • Conforms to ANSI/ASTM D178, TYPE II, CLASS 2.
    • Conforms to TABLE 3 for oil-resistance and flame-resistance.
    • Dielectric strength 30,000 volts A.C.
    • Proof tested at 20,000 volts A.C.
    • Recommended maximum use voltage is 17,000 A.C.
    • Corrugated pattern.
    • Black with Yellow Safety border.
    • Clearly marked with supplier name, ASTM D178, Type II, Class 2 on the back.

  17. Multi-Mat II Rubber Matting

    Multi-Mat II Rubber Matting (#0611)

    Starting at: $0.00

    • No other mat offers all these features.
    • Mat is not only reversible, but is also highly resistant to grease, oils, and fats.
    • Multi-Mat has excellent cushioned support, and is easy to clean.
    • Raised knobs facilitate drainage. Dirt and grease flush away easily.
    • Non-skid in even wet greasy conditions. Lightweight for ease of handling.
    • 3/8" thick
    • Custom sizes available

  18. Commercial Neoprene Sheet Rubber

    Commercial Neoprene Sheet Rubber (#1060)

    Starting at: $0.00

    • Neoprene blend provides moderate resistance to oil and ozone.
    • For use in bumpers, pads, and sealing in general gasket and flange applications.
    • Minimum tensile strength -800 PSI
    • Durometer 60 ±5
    • Temperature range -20° F to +170° F
    • Black color.

  19. Wayfarer Mats

    Wayfarer Mats (#265)

    $0.00
    • Vinyl loop construction traps dirt and moisture while scraping debris from shoes.
    • Thick vinyl foam backing helps keep the mat in place.
    • Tracking of dirt and moisture is minimized, protecting your clean floors and carpets.
    • Easy and inexpensive to maintain.
    • Just shake, vacuum or rinse out.
    • 3/8" thick.
    • Custom lengths available.

  20. Wayfarer Custom Mats

    Wayfarer Custom Mats (#266)

    $0.00
    • The perfect dirt stopper for outside and recessed applications.
    • This durable, vinyl loop mat, stands up to heavy traffic and scrapes dirt and grime off shoes.
    • This mat is unbacked to allow dirt and moisture to drain through for easy cleanup.
    • 1/2" thick.
    • Custom lengths available.

20 Item(s)
